A fluid science and technology research company specialising in the production and development of brushed and brushless motors, pump and valve components, etc., with a current annual production capacity of 5 million units.
Scope of application: vacuum pumps
Rated voltage: 12V
Rated flow rate: 5~7l/min
Rated current (no load): 500mA
Back pressure: -40pa
Pumping noise (1m): ≤ 75dB
Lifespan: can run continuously 500H;
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: vacuum pumps
Rated voltage: 12V
Rated flow rate: 2~3.5l/min
Rated current (no load): 250mA
Back pressure: -40pa
Pumping noise (1m): ≤ 65dB
Lifespan: can run continuously 250H; (corresponding to the life of relatively weak)
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: vacuum pumps
Rated voltage: 12V
Rated flow rate: 1~3L/min
Rated current (no load): 250mA
Back pressure: -40pa
Pumping noise (1m): ≤ 65dB
Lifespan: can run continuously 250H; (corresponding to the life of relatively weak)
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: diaphragm pumps
Rated voltage: 12V
Rated flow rate: 1000~2000ml/min
Rated current (no load): 650mA
Back pressure: -40pa
Pumping noise (1m): 60dB
Lifespan: can run continuously＞500H
Working temperature: 1℃~50℃, between 30%~85% relative humidity
Scope of application: diaphragm pumps
Rated voltage: 12V
Rated flow: 500~1000ml/min
Rated current (no load): 150mA
Back pressure: -40pa
Pumping noise (1m): ≤55dB
Lifespan: can run continuously＞500H
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: diaphragm pumps
Rated voltage: 5V
Rated flow: 150~250ml/min
Rated current (no load): 150mA
Back pressure: -25pa
Pumping noise (1m): ≤55dB
Lifespan: can run continuously for 250H
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: diaphragm pumps
Rated voltage: 5V
Rated flow: 50~100ml/min
Rated current (no load): 150mA
Back pressure: -25pa
Pumping noise (1m): ≤55dB
Lifespan: can run continuously＞500H
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: diaphragm pumps
Rated voltage: 12V
Rated flow: 30~50ml/min
Rated current (no load): 150mA
Back pressure: -20pa
Pumping noise (1m): ≤55dB
Lifespan: can run continuously for 250H
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
Scope of application: peristaltic pumps
Rated voltage: 12V
Rated flow: 200~450ml/min
Rated current (no load): ≤ 500mA
Back pressure: -40pa
Pumping noise (1m): ≤ 55dB
Scope of application: peristaltic pumps
Rated voltage: 12V
Rated flow: 6~15ml/min
Rated current (no load): ≤ 400mA
Back pressure: -40pa
Pumping noise (1m): ≤ 55dB
Lifespan: can run continuously 250H; (corresponding to the life of the relatively weak)
Working temperature: 1℃~50℃, relative humidity between 30%~85%;
